SCR/Diode Modules

Products
Show filter
Hidden filter
Reset

Show 18 products

  • Package
    • WMM01
    • WeEnPACK-20mm
    • WeEnTOP-B
    Reset filter
  • Configuration
    • Antiparallel SCRs
    • SCR + Diode
    • SCR Half-Bridge
    • SCR/Diode Half-Bridge
    • diode 3-phase bridge
    Reset filter
  • VRRM/VDRM(V)
    • 1200
    • 1600
    Reset filter
  • IT(AV)(A)
    • -
    • 40
    • 60
    • 75
    • 80
    • 100
    • 116
    • 140
    Reset filter
  • IT(RMS)(A)
    • -
    • 63
    • 94
    • 101
    • 125
    • 134
    • 157
    • 182
    • 220
    Reset filter
  • ITSM(A)
    • 750
    • 1150
    • 1500
    • 1700
    • 2000
    • 2300
    • 2800
    Reset filter
  • IGT(max)(mA)
    • -
    • 80
    • 100
    Reset filter
  • dVD/dt(V/us)
    • -
    • 150
    • 1500
    Reset filter
  • TVj(max)(℃)
    • 125
    • 150
    Reset filter
  • Qualification
    • Industrial
    Reset filter
  • Type Name
  • Compare
    Show All
  • Package
    • WMM01
    • WeEnPACK-20mm
    • WeEnTOP-B

    Reset filter

  • Configuration
    • Antiparallel SCRs
    • SCR + Diode
    • SCR Half-Bridge
    • SCR/Diode Half-Bridge
    • diode 3-phase bridge

    Reset filter

  • VRRM/VDRM(V)
    • 1200
    • 1600

    Reset filter

  • IT(AV)(A)
    • -
    • 40
    • 60
    • 75
    • 80
    • 100
    • 116
    • 140

    Reset filter

  • IT(RMS)(A)
    • -
    • 63
    • 94
    • 101
    • 125
    • 134
    • 157
    • 182
    • 220

    Reset filter

  • ITSM(A)
    • 750
    • 1150
    • 1500
    • 1700
    • 2000
    • 2300
    • 2800

    Reset filter

  • IGT(max)(mA)
    • -
    • 80
    • 100

    Reset filter

  • dVD/dt(V/us)
    • -
    • 150
    • 1500

    Reset filter

  • TVj(max)(℃)
    • 125
    • 150

    Reset filter

  • Qualification
    • Industrial

    Reset filter

  • WeEnPACK-20mm

    SCR Half-Bridge

    1600

    40

    63

    750

    80

    1500

    150

    Industrial

  • WeEnPACK-20mm

    SCR Half-Bridge

    1600

    60

    94

    1150

    100

    1500

    150

    Industrial

  • WeEnTOP-B

    Antiparallel SCRs

    1200

    -

    101

    1500

    100

    1500

    125

    Industrial

  • WeEnTOP-B

    SCR + Diode

    1200

    -

    101

    1500

    100

    1500

    125

    Industrial

  • WeEnTOP-B

    Antiparallel SCRs

    1600

    -

    101

    1500

    100

    1500

    125

    Industrial

  • WeEnPACK-20mm

    SCR Half-Bridge

    1200

    80

    125

    1700

    100

    1500

    150

    Industrial

  • WeEnPACK-20mm

    SCR/Diode Half-Bridge

    1600

    80

    125

    1700

    100

    1500

    150

    Industrial

  • WeEnPACK-20mm

    SCR Half-Bridge

    1600

    80

    125

    1700

    100

    150

    150

    Industrial

  • WeEnTOP-B

    Antiparallel SCRs

    1200

    -

    134

    2000

    100

    1500

    125

    Industrial

  • WeEnTOP-B

    SCR + Diode

    1200

    -

    134

    2000

    100

    1500

    125

    Industrial

  • WeEnTOP-B

    Antiparallel SCRs

    1600

    -

    134

    2000

    100

    1500

    125

    Industrial

  • WeEnPACK-20mm

    SCR Half-Bridge

    1600

    100

    157

    2000

    100

    1500

    150

    Industrial

  • WeEnPACK-20mm

    SCR Half-Bridge

    1600

    40

    63

    750

    80

    1500

    150

    Industrial

  • WeEnPACK-20mm

    SCR/Diode Half-Bridge

    1600

    116

    182

    2300

    100

    1500

    150

    Industrial

  • WeEnPACK-20mm

    SCR Half-Bridge

    1600

    140

    220

    2800

    100

    1500

    150

    Industrial

  • WeEnPACK-20mm

    SCR Half-Bridge

    1600

    116

    182

    2300

    100

    1500

    150

    Industrial

  • WMM01

    diode 3-phase bridge

    1600

    75

    -

    750

    -

    -

    150

    Industrial

  • WeEnPACK-20mm

    SCR Half-Bridge

    1600

    116

    182

    2300

    100

    1500

    150

    Industrial

  • WTMH40T16R
    • Package:

      WeEnPACK-20mm

    • Configuration:

      SCR Half-Bridge

    • VRRM/VDRM(V):

      1600

    • IT(AV)(A):

      40

    • IT(RMS)(A):

      63

    • ITSM(A):

      750

    • IGT(max)(mA):

      80

    • dVD/dt(V/us):

      1500

    • TVj(max)(℃):

      150

    • Qualification:

      Industrial

    Planar passivated Silicon Controlled Rectifier (SCR) module in TO-240AA for use in applications requiring high blocking voltage capability, high inrush current capability and high thermal cycling performance.

  • WTMH60T16R
    • Package:

      WeEnPACK-20mm

    • Configuration:

      SCR Half-Bridge

    • VRRM/VDRM(V):

      1600

    • IT(AV)(A):

      60

    • IT(RMS)(A):

      94

    • ITSM(A):

      1150

    • IGT(max)(mA):

      100

    • dVD/dt(V/us):

      1500

    • TVj(max)(℃):

      150

    • Qualification:

      Industrial

    Planar passivated Silicon Controlled Rectifier (SCR) module in TO-240AA for use in applications requiring high blocking voltage capability, high inrush current capability and high thermal cycling performance.

  • WAT100TBS12
    • Package:

      WeEnTOP-B

    • Configuration:

      Antiparallel SCRs

    • VRRM/VDRM(V):

      1200

    • IT(AV)(A):

      -

    • IT(RMS)(A):

      101

    • ITSM(A):

      1500

    • IGT(max)(mA):

      100

    • dVD/dt(V/us):

      1500

    • TVj(max)(℃):

      125

    • Qualification:

      Industrial

    Planar passivated Silicon Controlled Rectifier (SCR) module in WeEnTOP-B for use in applications requiring high blocking voltage capability, high inrush current capability and high thermal cycling performance.

  • WTD100TBS12
    • Package:

      WeEnTOP-B

    • Configuration:

      SCR + Diode

    • VRRM/VDRM(V):

      1200

    • IT(AV)(A):

      -

    • IT(RMS)(A):

      101

    • ITSM(A):

      1500

    • IGT(max)(mA):

      100

    • dVD/dt(V/us):

      1500

    • TVj(max)(℃):

      125

    • Qualification:

      Industrial

    Planar passivated Silicon Controlled Rectifier (SCR) module in WeEnTOP-B for use in applications requiring high blocking voltage capability, high inrush current capability and high thermal cycling performance.

  • WAT100TBS16
    • Package:

      WeEnTOP-B

    • Configuration:

      Antiparallel SCRs

    • VRRM/VDRM(V):

      1600

    • IT(AV)(A):

      -

    • IT(RMS)(A):

      101

    • ITSM(A):

      1500

    • IGT(max)(mA):

      100

    • dVD/dt(V/us):

      1500

    • TVj(max)(℃):

      125

    • Qualification:

      Industrial

    Planar passivated Silicon Controlled Rectifier (SCR) module in WeEnTOP-B for use in applications requiring high blocking voltage capability, high inrush current capability and high thermal cycling performance.

  • WTMH80T12R
    • Package:

      WeEnPACK-20mm

    • Configuration:

      SCR Half-Bridge

    • VRRM/VDRM(V):

      1200

    • IT(AV)(A):

      80

    • IT(RMS)(A):

      125

    • ITSM(A):

      1700

    • IGT(max)(mA):

      100

    • dVD/dt(V/us):

      1500

    • TVj(max)(℃):

      150

    • Qualification:

      Industrial

    Planar passivated Silicon Controlled Rectifier (SCR) module in WeEnPACK-20mm (TO-240AA) for use in applications requiring high blocking voltage capability, high inrush current capability and high thermal cycling performance

  • WHMH80T16
    • Package:

      WeEnPACK-20mm

    • Configuration:

      SCR/Diode Half-Bridge

    • VRRM/VDRM(V):

      1600

    • IT(AV)(A):

      80

    • IT(RMS)(A):

      125

    • ITSM(A):

      1700

    • IGT(max)(mA):

      100

    • dVD/dt(V/us):

      1500

    • TVj(max)(℃):

      150

    • Qualification:

      Industrial

    Planar passivated Silicon Controlled Rectifier (SCR) module in TO-240AA for use in applications requiring high blocking voltage capability, high inrush current capability and high thermal cycling performance.

  • WTMH80T16R
    • Package:

      WeEnPACK-20mm

    • Configuration:

      SCR Half-Bridge

    • VRRM/VDRM(V):

      1600

    • IT(AV)(A):

      80

    • IT(RMS)(A):

      125

    • ITSM(A):

      1700

    • IGT(max)(mA):

      100

    • dVD/dt(V/us):

      150

    • TVj(max)(℃):

      150

    • Qualification:

      Industrial

    Planar passivated Silicon Controlled Rectifier (SCR) module in TO-240AA for use in applications requiring high blocking voltage capability, high inrush current capability and high thermal cycling performance.

  • WAT120TBS12
    • Package:

      WeEnTOP-B

    • Configuration:

      Antiparallel SCRs

    • VRRM/VDRM(V):

      1200

    • IT(AV)(A):

      -

    • IT(RMS)(A):

      134

    • ITSM(A):

      2000

    • IGT(max)(mA):

      100

    • dVD/dt(V/us):

      1500

    • TVj(max)(℃):

      125

    • Qualification:

      Industrial

    Planar passivated Silicon Controlled Rectifier (SCR) module in WeEnTOP-B for use in applications requiring high blocking voltage capability, high inrush current capability and high thermal cycling performance.

  • WTD120TBS12
    • Package:

      WeEnTOP-B

    • Configuration:

      SCR + Diode

    • VRRM/VDRM(V):

      1200

    • IT(AV)(A):

      -

    • IT(RMS)(A):

      134

    • ITSM(A):

      2000

    • IGT(max)(mA):

      100

    • dVD/dt(V/us):

      1500

    • TVj(max)(℃):

      125

    • Qualification:

      Industrial

    Planar passivated Silicon Controlled Rectifier (SCR) module in WeEnTOP-B for use in applications requiring high blocking voltage capability, high inrush current capability and high thermal cycling performance.

  • WAT120TBS16
    • Package:

      WeEnTOP-B

    • Configuration:

      Antiparallel SCRs

    • VRRM/VDRM(V):

      1600

    • IT(AV)(A):

      -

    • IT(RMS)(A):

      134

    • ITSM(A):

      2000

    • IGT(max)(mA):

      100

    • dVD/dt(V/us):

      1500

    • TVj(max)(℃):

      125

    • Qualification:

      Industrial

    Planar passivated Silicon Controlled Rectifier (SCR) module in WeEnTOP-B for use in applications requiring high blocking voltage capability, high inrush current capability and high thermal cycling performance.

  • WTMH100T16R
    • Package:

      WeEnPACK-20mm

    • Configuration:

      SCR Half-Bridge

    • VRRM/VDRM(V):

      1600

    • IT(AV)(A):

      100

    • IT(RMS)(A):

      157

    • ITSM(A):

      2000

    • IGT(max)(mA):

      100

    • dVD/dt(V/us):

      1500

    • TVj(max)(℃):

      150

    • Qualification:

      Industrial

    Planar passivated Silicon Controlled Rectifier (SCR) module in TO-240AA for use in applications requiring high blocking voltage capability, high inrush current capability and high thermal cycling performance

  • WTMH40T16
    • Package:

      WeEnPACK-20mm

    • Configuration:

      SCR Half-Bridge

    • VRRM/VDRM(V):

      1600

    • IT(AV)(A):

      40

    • IT(RMS)(A):

      63

    • ITSM(A):

      750

    • IGT(max)(mA):

      80

    • dVD/dt(V/us):

      1500

    • TVj(max)(℃):

      150

    • Qualification:

      Industrial

    Planar passivated Silicon Controlled Rectifier (SCR) module in WeEnPACK-20mm (TO-240AA) for use in applications requiring high blocking voltage capability, high inrush current capability and high thermal cycling performance.

  • WHMH116T16
    • Package:

      WeEnPACK-20mm

    • Configuration:

      SCR/Diode Half-Bridge

    • VRRM/VDRM(V):

      1600

    • IT(AV)(A):

      116

    • IT(RMS)(A):

      182

    • ITSM(A):

      2300

    • IGT(max)(mA):

      100

    • dVD/dt(V/us):

      1500

    • TVj(max)(℃):

      150

    • Qualification:

      Industrial

    Planar passivated Silicon Controlled Rectifier (SCR) module in TO-240AA for use in applications requiring high blocking voltage capability, high inrush current capability and high thermal cycling performance.

  • WTMH140T16R
    • Package:

      WeEnPACK-20mm

    • Configuration:

      SCR Half-Bridge

    • VRRM/VDRM(V):

      1600

    • IT(AV)(A):

      140

    • IT(RMS)(A):

      220

    • ITSM(A):

      2800

    • IGT(max)(mA):

      100

    • dVD/dt(V/us):

      1500

    • TVj(max)(℃):

      150

    • Qualification:

      Industrial

    Planar passivated Silicon Controlled Rectifier (SCR) module in TO-240AA for use in applications requiring high blocking voltage capability, high inrush current capability and high thermal cycling performance.

  • WTMH116T16
    • Package:

      WeEnPACK-20mm

    • Configuration:

      SCR Half-Bridge

    • VRRM/VDRM(V):

      1600

    • IT(AV)(A):

      116

    • IT(RMS)(A):

      182

    • ITSM(A):

      2300

    • IGT(max)(mA):

      100

    • dVD/dt(V/us):

      1500

    • TVj(max)(℃):

      150

    • Qualification:

      Industrial

    Planar passivated Silicon Controlled Rectifier (SCR) module in TO-240AA for use in applications requiring high blocking voltage capability, high inrush current capability and high thermal cycling performance.

  • WDMF75M16
    • Package:

      WMM01

    • Configuration:

      diode 3-phase bridge

    • VRRM/VDRM(V):

      1600

    • IT(AV)(A):

      75

    • IT(RMS)(A):

      -

    • ITSM(A):

      750

    • IGT(max)(mA):

      -

    • dVD/dt(V/us):

      -

    • TVj(max)(℃):

      150

    • Qualification:

      Industrial

    Three phase Rectifier Bridge in a WMM01 package.

  • WTMH116T16R
    • Package:

      WeEnPACK-20mm

    • Configuration:

      SCR Half-Bridge

    • VRRM/VDRM(V):

      1600

    • IT(AV)(A):

      116

    • IT(RMS)(A):

      182

    • ITSM(A):

      2300

    • IGT(max)(mA):

      100

    • dVD/dt(V/us):

      1500

    • TVj(max)(℃):

      150

    • Qualification:

      Industrial

    Planar passivated Silicon Controlled Rectifier (SCR) module in TO-240AA for use in applications requiring high blocking voltage capability, high inrush current capability and high thermal cycling performance.
